TODIMART X-17 Mobility Scooter User Manual

1. הקדמה און איבערview

The TODIMART X-17 is a lightweight, foldable 4-wheel mobility scooter designed for comfort and ease of use. It features a robust aluminum frame and is ideal for individuals seeking reliable and convenient personal transportation.

שליסל פֿעיִקייטן:

• עקסטענדעד קייט: Equipped with a removable 10.4 Ah lithium battery, offering a range of up to 30 km. The battery can be charged separately for convenience.
• זיכערקייַט ערשטער: Features an ultra-bright LED front light for visibility, anti-tip rear wheels for stability, and an electromagnetic braking system for optimal stopping power.
• באַקוועם פּלאַן: Includes a soft, comfortable seat with fully adjustable lumbar and arm supports, ensuring a pleasant ride.
• גלאַט אָפּעראַציע: 8-inch wheels provide enhanced stability and a smooth driving experience, with a maximum speed of 8 km/h.
• פּאָרטאַטיוו און סאָליד: Weighing 20.7 kg, the X-17 folds in just 3 seconds, making it easy to store and transport, fitting conveniently into a car trunk.

TODIMART X-17 Mobility Scooter with key features: Easy charging, 30 km battery range, 8-inch airless tires, front anti-theft lock, foldable and portable, electromagnetic braking system. Displays 8 km/h speed, 130 kg load capacity, 30 km maximum range.

2. סעטאַפּ און אַסעמבלי

The TODIMART X-17 scooter is designed for quick and easy setup. Follow these steps to prepare your scooter for first use.

2.1 אַנפּאַקינג

1. נעמט פֿאָרזיכטיק אַרויס דעם סקוטער און אַלע אַקסעסאָריעס פֿון דער פּאַקאַדזשינג.
2. Inspect the scooter for any signs of damage during transit. Contact customer support immediately if any damage is found.

2.2 אויסלייגן דעם סקוטער

The X-17 features a rapid folding mechanism:

1. שטעלט דעם סקוטער אויף א גלאַטער, סטאַבילער ייבערפלאַך.
2. Release the folding latch (refer to the diagram in the manual for exact location).
3. Gently unfold the scooter until it locks into its upright position. Ensure all locking mechanisms are securely engaged.

2.3 באַטעריע אינסטאַלאַציע און ערשטע אָפּצאָל

The scooter uses a removable lithium battery:

1. געפינען די באַטאַרייע אָפּטייל.
2. Insert the 10.4 Ah lithium battery into its compartment, ensuring a secure connection.
3. For first use, fully charge the battery. Connect the charger to the scooter's charging port or remove the battery and charge it separately. A full charge typically takes 4-6 hours.

2.4 Seat and Handlebar Adjustment

Adjust the seat and handlebars for optimal comfort and control:

• Adjust the seat height and position to ensure your feet can comfortably reach the ground and you have a clear view פון די קאָנטראָלס.
• Adjust the armrests and lumbar support as needed for comfort.
• Ensure the handlebars are at a comfortable height and angle for steering.

Secure and practical mobility. The image shows the scooter's folding mechanism and various storage compartments. Features include a fully enveloping seat, multiple storage compartments, and a folding/storing function. Detailed views show the side storage pocket, front basket, USB charging port, and the seat folding.

3. אַפּערייטינג ינסטרוקטיאָנס

Familiarize yourself with the control panel and operating procedures before riding your TODIMART X-17 scooter.

3.1 קאָנטראָל פּאַנעל איבערview

Simple Control Panel. Close-up of the scooter's handlebar controls: Speed display, key slot, speed adjustment button, forward/reverse switch, handlebar grips (both sides), headlight button, and USB port.

• גיכקייַט ווייַז: ווייזט קראַנט גיכקייַט.
• Key Slot: Insert key to power on/off.
• ספּיד אַדזשאַסטמאַנט קנעפּל: Controls the maximum speed setting.
• פאָרווערטס/צוריקקער סוויטש: אויסקלייבט די ריכטונג פון די דרייווינג.
• כאַנדלעבאַר גריפּס: Used for acceleration and steering.
• הענדלייט קנעפל: Activates the front LED headlight.
• וסב פּאָרט: For charging compatible electronic devices.

3.2 אָנפֿאַנגען און פֿאָרן

1. Insert the key into the key slot and turn it to the 'ON' position. The speed display will illuminate.
2. Adjust your desired speed using the speed adjustment button.
3. Select 'Forward' or 'Reverse' using the directional switch.
4. Gently press the handlebar grips to accelerate. Release to slow down.
5. Steer by turning the handlebars.

3.3 ברייקינג

The TODIMART X-17 is equipped with an electromagnetic braking system:

• To brake, simply release the handlebar grips. The scooter will automatically slow down and stop.
• For emergency stops, fully release the grips.

3.4 פאָרליכט אָפּעראַציע

Press the headlight button on the control panel to turn the front LED headlight on or off. Use the headlight in low-light conditions or at night for improved visibility.

Bright Front Headlight. Provides good visibility in dark environments like night, fog, or tunnels, making driving safer.

4. וישאַלט

Regular maintenance ensures the longevity and optimal performance of your TODIMART X-17 mobility scooter.

4.1 באַטערי קער

• לאָדט די באַטאַרייע רעגולער, אפילו אויב דער סקוטער ווערט נישט אָפט גענוצט, כּדי צו האַלטן די באַטאַרייע געזונט.
• פֿאַרמײַדט גאָר אויסצוליידיקן די באַטעריע איידער איר לאָזט עס איבער.
• Store the battery in a cool, dry place if removed from the scooter for extended periods.

4.2 רייניקונג

• ווישט אַראָפּ דעם סקוטער מיט אַדamp שטאָף. פֿאַרמײַדט ניצן אַברייסיוו רייניגער אָדער סאָלווענטן וואָס קענען שאַטן די ענדיקונג.
• Do not use high-pressure water jets directly on electrical components.

4.3 רעדער דורכקוק

• Periodically inspect the 8-inch puncture-proof tires for any signs of wear or damage.
• While puncture-proof, ensure no debris is lodged in the tires.

4.4 אַלגעמיינע טשעקס

• קאָנטראָלירט רעגולער אַלע ניסלעך, באָלץ און פאַסטאַנינגז צו זיכער מאַכן אַז זיי זענען פעסט.
• Inspect the wiring and connections for any signs of fraying or damage.
• Ensure the electromagnetic brakes engage smoothly and effectively.

5. טראָובלעשאָאָטינג

This section addresses common issues you might encounter with your TODIMART X-17 scooter.

5.1 Scooter Not Starting

• טשעק באַטאַרייע טשאַרדזש: ענשור אַז די באַטאַרייע איז גאָר באפוילן.
• שליסל שטעלע: Verify the key is fully inserted and turned to the 'ON' position.
• באַטערי קשר: Ensure the battery is properly seated and connected in its compartment.

5.2 Reduced Range or Power

• באַטאַרייע אָפּצאָל: Confirm the battery is fully charged before each use.
• לאָדן: Operating with a load close to the maximum capacity (130 kg) or on steep inclines can reduce range.
• רעדער צושטאַנד: While puncture-proof, worn tires can affect efficiency.

High-performance, long-lasting lithium battery. An elderly man rides the scooter, illustrating its range capabilities: 5 km to home, 10 km to churches, 20 km to clinics, 30 km to parks. Battery specifications: 24V 10.4AH capacity, 270W motor power, 4-6 hours charging time.

5.3 ברעיקינג פראבלעמען

• If the electromagnetic brakes are not engaging or releasing correctly, cease operation immediately.
• Contact TODIMART customer support for assistance.

5.4 אומגעוויינטלעכע גערוישן

• If you hear unusual noises during operation, stop the scooter and inspect for loose parts or obstructions.
• אויב דער ראַש בלייבט, קאָנטאַקטירט קונה שטיצע.

6. ספּעסאַפאַקיישאַנז

Detailed technical specifications for the TODIMART X-17 Mobility Scooter.

Scooter dimensions and weight. Top view shows overall dimensions: 1000mm length, 505mm width, 920mm height. Seat dimensions: 375mm width, 320mm depth, 300mm backrest height. Basket parameters: 2.4 L capacity, 15 kg max load. Folded dimensions: 1000mm length, 505mm width, 355mm height. Total vehicle weight: 20.7 kg.

Powerful 270W motor. Ensures safety when driving on inclines. Insets show puncture-proof tires and anti-slip rear wheels. The scooter can navigate inclines of up to 12 degrees safely.

7. וואָראַנטי און שטיצן

7.1 וואָראַנטי אינפֿאָרמאַציע

The TODIMART X-17 Mobility Scooter comes with a standard manufacturer's warranty. For specific details regarding warranty coverage, duration, and terms, please refer to the warranty card included in your product packaging. You may also contact TODIMART customer support for further information.

7.2 קונה שטיצן

For technical assistance, inquiries about spare parts, or any other support needs, please contact TODIMART customer support. You can find contact information on the product packaging or by visiting the official TODIMART store on Amazon:
