1. הקדמה
This manual provides essential information for the safe and effective use of your SZSWWPOR 12V AC/DC Adapter. This power supply is designed to provide reliable power to compatible AeroGarden Harvest series indoor garden LED grow lights. Please read these instructions thoroughly before use and retain them for future reference.
Image 1.1: SZSWWPOR 12V AC/DC Adapter. This image displays the compact black power adapter with its attached power cord and round tip connector.
2. וויכטיק סאַפעטי אינפֿאָרמאַציע
כדי צו זיכער מאַכן זיכערע אָפּעראַציע און פאַרמייַדן שאָדן, זאָלט איר זיך האַלטן צו די פאלגענדע זיכערהייט גיידליינז:
- Voltage קאַמפּאַטאַבילאַטי: This adapter provides 12V רעזולטאַט. DO NOT use with 24V devices. באַשטעטיקן דיין מיטל'ס באַנדtagE רעקווירעמענץ איידער קאַנעקטינג.
- בלויז דרינענדיק נוצן: This adapter is designed for indoor use in dry environments. Avoid exposure to moisture, rain, or extreme temperatures.
- געהעריק קשר: Ensure the adapter is fully plugged into both the wall outlet and the device. A loose connection can cause overheating or malfunction.
- קאַבלע זאָרגן: בייגט, דרייט אדער ציט נישט דעם עלעקטרישן שנור צו פיל. פארמיידט צו לייגן שווערע אביעקטן אויפן שנור.
- דיסקאַנעקשאַן: Always grasp the plug, not the cord, when disconnecting from the power outlet.
- שעדיקן: If the adapter or cord is damaged, discontinue use immediately and replace it with a suitable alternative.
- סערטיפיקאַטיאָנס: This SZSWWPOR Charger is certified with CE and ROHS standards, ensuring quality and safety.
Image 2.1: Internal cable construction and safety features. This image illustrates the multi-layered construction of the cable (high-grade copper, aluminum foil shield, wire insulation, protective tinned copper braid, PVC cable jacket) and lists safety protections such as over voltage, over temperature, short circuit, and over charge/discharge protection.
3. פּראָדוקט איבערview און פֿעיִקייטן
The SZSWWPOR 12V AC/DC Adapter is a high-quality power supply designed for durability and stable performance. It features:
- סטאַביל רעזולטאַט: Provides a consistent 12V DC output for reliable device operation.
- Premium Copper Wire: The power cord is constructed with high-grade copper, designed to withstand regular use without damage.
- קייפל שוץ: כולל איבער וואָלtage Protection, Over Heat Protection, Short Circuit Protection, and Over Charge/Discharge Protection.
- סאָליד פּלאַן: Easy to transport and store, suitable for various indoor settings.
Image 3.1: Demonstrates the cable's flexibility and stable output. The image shows hands stretching the power cord, highlighting its durable and flexible nature.
בילד 3.2: דעטאַלירט view of the premium copper wire construction. This image shows a cross-section of the power cable, revealing high-grade copper wires, aluminum foil shield, wire insulation, and PVC cable jacket.
4. קאַמפּאַטאַבילאַטי
This 12V AC/DC Adapter is compatible with the following AeroGarden Harvest series models:
- AeroGarden Harvest (Model numbers: 100690-BLK/GRY/WHT/RED, 100690)
- AeroGarden Harvest 360 (Model numbers: 100692-BLK/WHT/RED, 100692)
- AeroGarden Harvest Slim (Model numbers: 100694-BLK/WHT/SGE, 100694)
- AeroGarden Harvest Elite (Model numbers: 100691-PPL/BSS/PCP/PSG, 100691)
- AeroGarden Harvest Elite 360 (Model numbers: 100693-PPL/BSS/PCP/PRE, 100693)
- AeroGarden Harvest Elite Slim (Model numbers: 100695-PPL/BSS/PCP, 100695)
Important Note: This adapter provides 12V output. It is NOT compatible with 24V versions of AeroGarden devices.
5. אויפשטעלן און באַניץ
- באַשטעטיקן קאַמפּאַטאַבילאַטי: Before connecting, ensure your AeroGarden model requires a 12V DC, 2.5A power supply.
- פאַרבינדן צו מיטל: Insert the round tip connector of the adapter firmly into the power input port of your AeroGarden unit.
- פאַרבינדן צו מאַכט אָוטלעט: Plug the AC end of the adapter into a standard 110V AC wall outlet.
- מאַכט אויף: Your AeroGarden device should now receive power. Follow your AeroGarden's specific instructions for operation.
Image 5.1: Illustrates the adapter's versatility for charging in various environments such as office, home, travel, and outdoor settings.
6. ספּעסאַפאַקיישאַנז
| שטריך | דעטאַל |
|---|---|
| אַרייַנשרייַב וואָלtage | 110 וואלטס (AC) |
| רעזולטאַט חלקtage | 12 וואלטס (דק) |
| Ampעראַגע | 2.5 Amps |
| וואָסtage | 30 וואטס |
| קאַנעקטער טיפּ | קייַלעכיק שפּיץ |
| קאָליר | שוואַרץ |
| פּונקט וואָג | 4.6 אונסעס |
| פּעקל דימענשאַנז | 5.43 X 2.8 X 2.76 אינטשעס |
Image 6.1: Visual representation of the adapter's dimensions, shown in comparison to a credit card for scale.
7. וישאַלט
- רייניקונג: Disconnect the adapter from power before cleaning. Use a dry, soft cloth to wipe the exterior. Do not use liquid cleaners.
- סטאָרידזש: Store the adapter in a cool, dry place when not in use. Avoid wrapping the cord too tightly around the adapter.
- דורכקוק: Periodically inspect the adapter and cord for any signs of damage, such as fraying, cuts, or exposed wires.
8. טראָובלעשאָאָטינג
- קיין מאַכט צו דיווייס:
- זיכער מאַכן אַז דער אַדאַפּטער איז זיכער אַרייַנגעשטעקט אין ביידע די וואַנט ווענטיל און דעם מיטל.
- קאָנטראָלירט צי די וואַנט אַוטלעט אַרבעט דורך אַרײַנשטעקן אַן אַנדער דעוויס.
- Verify that your device requires a 12V power supply, not 24V.
- Inspect the adapter and cord for visible damage.
- אַדאַפּטער אָוווערכיטינג:
- Disconnect the adapter immediately.
- Ensure the adapter is not covered or in an enclosed space that restricts airflow.
- Confirm the device's power requirements do not exceed the adapter's 2.5A capacity.
9. וואָראַנטי און שטיצן
For any questions, concerns, or support regarding your SZSWWPOR 12V AC/DC Adapter, please refer to the seller's contact information or the platform where the product was purchased. This product is designed for reliability and performance.
