Yaheetech Queen Upholstered Bed Frame

וויכטיק סאַפעטי אינפֿאָרמאַציע

ביטע ליינט און פארשטייט אלע אינסטרוקציעס איידער איר שטעלט עס צוזאם און ניצט עס. האלט דעם מאנואל פאר שפעטערדיגע רעפערענץ.

• וואָג קאַפּאַציטעט: נישט איבערשטייגן די מאקסימום וואָג קאַפּאַציטעט פון 794 פונט (360 ק"ג).
• קאָפּבאָרד אַדזשאַסטמאַנט: Be cautious when adjusting the headboard height to prevent injury. Ensure all fasteners are securely tightened after adjustment.
• פֿאַרזאַמלונג: Assemble the bed frame on a soft, clean surface to prevent scratches. Ensure all parts are present before beginning assembly.
• וישאַלט: Regularly check all bolts and connections to ensure they remain tight. Loose connections can lead to instability and potential injury.
• קינדער: האַלט קליינע טיילן און פּאַקאַדזשינג מאַטעריאַלן אַוועק פון קינדער צו ויסמיידן דערשטיקונג געפאַרן.

פּעקל אינהאַלט

Verify that all components listed below are present before starting assembly. Refer to the assembly video for visual identification of parts.

בילד: עקספּלאָדעד view of all bed frame components, including headboard, side rails, center support bars, legs, wooden slats, and hardware. Each part is labeled for easy identification during assembly.

רשימה פון טיילן:

• A: Headboard (1 pc)
• B: Left Side Rail (1 pc)
• C1/C2: Wooden Slats (12 pcs total)
• ד1/ד2: Center Support Bars (2 pcs)
• E: Right Side Rail (1 pc)
• F: Headboard Support Legs (2 pcs)
• G: Center Support Leg (1 pc)
• H: Cross Support Bar (1 pc)
• I: Bed Legs (4 pcs)
• J: Headboard Brackets (2 pcs)
• K: Center Support Brackets (2 pcs)
• L: Corner Brackets (4 pcs)
• M: Side Rail Connectors (2 pcs)
• N: Footboard Connectors (2 pcs)
• O: Bolts (various sizes)
• P: Washers (various sizes)
• Q: Allen Wrench (1 פּיסי)
• R: שרויפן (פאַרשידענע גרייסן)
• S: Nuts (various sizes)

אַסעמבלי אינסטרוקציעס

Follow these steps carefully for proper assembly. An assembly video is provided for visual guidance.

שריט-דורך-שריט גייד:

1. צוטשעפּען קאָפּבאָרד שטיצע פֿיס: Securely attach the Headboard Support Legs (F) to the Headboard (A) using the provided bolts (O) and washers (P). Use the Allen wrench (Q) to tighten.
2. צוזאַמענשטעלן זייט רעלסן: Connect the Left Side Rail (B) and Right Side Rail (E) to the Headboard Support Legs (F) using the Side Rail Connectors (M) and appropriate hardware. Ensure a snug fit.
3. Install Center Support Bars: Attach the Center Support Bars (D1, D2) to the side rails. Connect the Cross Support Bar (H) between the two center support bars using bolts (O) and nuts (S).
4. Attach Center Support Legs: Fasten the Center Support Leg (G) to the Cross Support Bar (H) for additional stability.
5. Install Bed Legs: Screw the Bed Legs (I) into the designated corners of the bed frame.
6. שטעל האָלצערנע לאַטעס: Lay the Wooden Slats (C1, C2) across the bed frame. Secure them in place using the hook & loop fasteners or screws (R) as indicated in the video. Ensure even spacing for optimal mattress support.
7. לעצט טייטנינג: Double-check all bolts and screws to ensure they are fully tightened before placing the mattress on the frame.

אַפּערייטינג ינסטראַקשאַנז

Height-Adjustable Headboard:

The upholstered headboard can be adjusted to your preferred height. It ranges from 44.5 inches to 48.5 inches. To adjust, loosen the bolts connecting the headboard to its support legs, slide the headboard to the desired height, and then securely re-tighten the bolts. This allows for optimal comfort when reading or relaxing in bed.

בילד: A visual representation of the headboard's height adjustment mechanism, illustrating the range of 44.5 to 48.5 inches.

קיין באָקס ספּרינג נייטיק:

This platform bed frame is designed to support your mattress directly, eliminating the need for a box spring. Simply place your latex, foam, or spring mattress on the wooden slats after assembly.

וישאַלט

• רייניקונג: Wipe the bed frame with a dry cloth to remove dust and debris. For upholstered areas, use a soft brush or vacuum with an upholstery attachment. Avoid harsh chemicals or abrasive cleaners.
• רעגולער טשעקס: Periodically inspect all screws, bolts, and connections to ensure they are tight. Re-tighten any loose fasteners to maintain stability and prevent squeaking.
• אונטערבעט פּלאַץ: The 6.3-inch ground clearance allows for easy cleaning underneath the bed, including access for robotic vacuum cleaners.

בילד: A robot vacuum cleaner operating beneath the bed frame, demonstrating the convenient 6.3-inch underbed clearance for cleaning.

טראָובלעשאָאָטינג

• קוויטשענדיקע גערוישן: If the bed frame makes squeaking noises, check all bolts and screws. Tighten any loose fasteners. The frame is designed with EVA foam to minimize noise, but periodic checks are recommended.
• אינסטאביליטעט/וואקלען: Ensure all connections are fully tightened. Verify that the center support legs are properly installed and making firm contact with the floor.
• Slats Shifting: Ensure the wooden slats are correctly positioned and secured by their hook & loop fasteners or screws. If any slats are damaged, contact customer support for replacements.

ספּעסאַפאַקיישאַנז

בילד: Detailed dimensions of the Yaheetech Queen Upholstered Bed Frame, including length, width, and adjustable headboard height.

וואָראַנטי און שטיצן

For warranty information, replacement parts, or further assistance, please contact Yaheetech customer support. Refer to your purchase documentation for specific warranty terms and contact details.

You can also visit the official Yaheetech store for more products and support: יאַהעעטעק קראָם
