1. פּראָדוקט איבערview
The VONROC 5L Pressure Sprayer, Model PS504DC, is a battery-powered device designed for various spraying tasks in your garden. It features an integrated 4V battery, an LED display for battery status, and comes with two interchangeable spray lances for different applications. The included shoulder strap enhances portability, and the USB charging cable allows for convenient recharging.
2. זיכערקייַט אינסטרוקציעס
Read all safety warnings and instructions before using this product. Failure to follow the warnings and instructions may result in electric shock, fire, and/or serious injury.
- אַלגעמיינע זיכערקייַט: Keep the work area clean and well-lit. Do not operate the sprayer in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust.
- פערזענליכע זיכערקייט: Always wear appropriate personal protective equipment, including eye protection, gloves, and a mask, especially when spraying chemicals. Avoid accidental starting. Ensure the switch is in the off-position before connecting to a battery pack, picking up or carrying the appliance.
- Sprayer Use and Care: Do not spray flammable, corrosive, or highly toxic liquids. Do not modify the sprayer. Do not immerse the sprayer in water. Keep children and bystanders away while operating the sprayer.
- באַטערי נוצן און זאָרגן: Recharge only with the charger specified by the manufacturer. Use the appliance only with specifically designated battery packs. Do not use a battery pack or appliance that is damaged or modified.
- וישאַלט: Have your sprayer serviced by a qualified repair person using only identical replacement parts.
3. פּעקל אינהאַלט
Verify that all items listed below are present and in good condition upon unpacking your VONROC 5L Pressure Sprayer.
- 1x VONROC 5L Pressure Sprayer Unit (with integrated 4V battery)
- 1x Spray Handle
- 2x Spray Lances (different lengths/patterns)
- 1x אַקסל רימען
- 1 קס וסב טשאַרדזשינג קאַבלע
- 1x באַניצער מאַנואַל
4. אַסעמבלי און סעטאַפּ
4.1 אַטאַטשינג די אַקסל רימען
- Locate the attachment points on the sprayer unit.
- Clip each end of the shoulder strap securely to these points.
- סטרויערן די רימען לענג פֿאַר באַקוועם קעריינג.
4.2 Connecting the Spray Lances
- Select the desired spray lance for your task.
- Attach the chosen lance to the spray handle by twisting it clockwise until secure.
- Connect the hose from the sprayer unit to the spray handle. Ensure a tight connection to prevent leaks.
4.3 טשאַרדזשינג די באַטאַרייע
Before first use, fully charge the integrated 4V battery.
- Locate the USB charging port on the sprayer unit.
- Connect the provided USB charging cable to the sprayer and to a compatible USB power adapter (not included).
- The LED display will indicate charging status. Charge until the display shows a full charge.
4.4 פילונג דעם טאַנק
- Ensure the sprayer is turned off.
- ונסקרעוו די טאַנק היטל.
- Pour the desired liquid (water, non-corrosive plant food, etc.) into the tank, observing the 5L maximum fill line.
- שרויבט צוריק אָן דעם טאַנק דעקל זיכער.
5. אַפּערייטינג ינסטרוקטיאָנס
5.1 פּאַוערינג אויף / אַוועק
Press the power button on the spray handle to turn the sprayer on. Press it again to turn it off.
5.2 Spraying Technique
- With the sprayer powered on, aim the spray lance at the target area.
- Press and hold the trigger on the spray handle to begin spraying.
- מעלדונג די צינגל צו האַלטן ספּרייינג.
5.3 Adjusting Spray Pattern
The sprayer comes with two lances, offering different spray patterns. To change the pattern, replace the currently attached lance with the other one as described in Section 4.2.
5.4 געפֿירט ווייַז
The LED display on the sprayer unit indicates the current battery charge level. Monitor this display to ensure sufficient power for your tasks and to know when recharging is necessary.
6. וישאַלט
6.1 Cleaning the Tank and Nozzle
- נאָך יעדער נוצן, ליידיק קיין רוען פליסיק פון דעם טאַנק.
- שווענקען די טאַנק ונ דורך מיט ריין וואַסער.
- Spray clean water through the lance for a few seconds to clear any residue from the hose and nozzle.
- If the nozzle becomes clogged, remove it and clean it with a soft brush or by rinsing under running water.
6.2 באַטעריע זאָרג און סטאָרידזש
- האַלט דעם שפּריץ־מאַשין אין אַ קיל, טרוקן אָרט, אַוועק פון דירעקטער זון און עקסטרעמע טעמפּעראַטורן.
- For long-term storage, ensure the battery is partially charged (around 50-70%) to prolong its lifespan. Avoid storing with a completely empty or full battery.
- Recharge the battery every 3-6 months during long storage periods.
6.3 ווינטער סטאָרידזש
If storing the sprayer for winter, ensure it is completely empty and dry to prevent freezing and damage to components.
7. טראָובלעשאָאָטינג
| פּראָבלעם | מעגלעך סיבה | לייזונג |
|---|---|---|
| ספּרייער טוט נישט קער אויף | די באַטאַרייע איז ליידיק | טשאַרדזשינג די באַטאַרייע מיט די וסב קאַבלע. |
| קיין שפּריץ אָדער שוואַך שפּריץ | טאַנק איז ליידיק | Refill the tank with liquid. |
| נעזל איז קלאָגד | Clean the nozzle as described in Section 6.1. | |
| Hose or connections are loose | Check all hose connections and tighten if necessary. | |
| Liquid leaks from connections | קאַנעקשאַנז זענען נישט ענג | Ensure all connections (tank cap, hose to handle, lance to handle) are securely tightened. |
8. טעכניש ספּעסאַפאַקיישאַנז
- מאָדעל: PS504DC
- סאָרט: VONROC
- טאַנק באַנד: 5 ליטער
- באַטערי: Integrated 4V
- טשאַרדזשינג: וסב (קאַבלע אַרייַנגערעכנט)
- מאַטעריאַל: פּלאַסטיק
- שלאַנג לענג: 1.4 מעטער
- פּראָדוקט דימענשאַנז (L x W x H): 34 X 18 X 24 סענטימעטער
- נומער וואָג: 1.4 קג
- קאָליר: געל און שווארצע
- רעקאַמענדיד נוצן: וואָטערינג
9. וואָראַנטי און שטיצן
VONROC products are designed to meet high-quality standards. This product typically comes with a 24-month warranty from the date of purchase. For warranty claims, technical support, or spare parts inquiries, please contact VONROC customer service directly. Keep your proof of purchase for warranty validation.
For further assistance, please visit the official VONROC webזייטל אדער קאנטאקט זייערע קאסטומער שטיצע קאנאלן.
