LoraTap Smart WiFi Bulb Socket E26 Instruction Manual

1. פּראָדוקט איבערview

The LoraTap Smart WiFi Bulb Socket E26 transforms your standard light bulbs into smart, app-controlled devices. This adapter allows for voice control via Amazon Alexa and Google Home, remote control through the Smart Life app, and programmable timers and schedules. It is designed for use with E26 base LED, CFL, Fluorescent, and Corn bulbs, with a maximum power output of 30W.

2. זיכערקייַט אינפֿאָרמאַציע

• This device is designed for use with LED, CFL, Fluorescent, and Corn bulbs only.
• Do not use with Incandescent, Halogen, or Tungsten bulbs. Using incompatible bulb types may damage the smart socket.
• פאַרזיכערן די גאַנץ וואַסערtage of the connected bulb does not exceed 30W.
• בלויז פֿאַר דרינענדיק נוצן.
• Always disconnect power before installation or removal.

The image below illustrates compatible and incompatible bulb types.

בילד: Lamp Compatibility Confirmation. This image shows green checkmarks for LED, Fluorescent, CFL, and Corn bulbs, indicating compatibility. Red crosses are shown over Dimmer Light, Incandescent, Tungsten, and Halogen lamps, indicating incompatibility. A note states: 'NOT work with dimmer lights, incandescent, tungsten or halogen lamps, otherwise it will damage the light socket.'

3. ספּעסאַפאַקיישאַנז

The image below provides a visual representation of the product dimensions.

בילד: Product Dimensions. This diagram shows the dimensions of the E26 smart bulb socket, including its width (2.68 inches), total height (2.83 inches), and the added length to the light fixture (1.58 inches).

4. סעטאַפּ גייד

4.1 פאַר-ינסטאַלירונג טשעקס

• Wi-Fi נעטוואָרק: Ensure your Wi-Fi network is 2.4GHz. This device does not support 5GHz Wi-Fi or consolidated 2.4GHz/5GHz dual-band networks where the bands cannot be separated.
• ראַוטער נאָענטקייט: The smart socket should be installed within 10 meters (approximately 30 feet) of your Wi-Fi router for optimal signal strength during pairing and operation.

בילד: Installation Distance. This image illustrates that the device should be within 10 meters of the Wi-Fi router for a good signal, showing a green happy face for <10m and a red sad face for >10m.

4.2 ינסטאַללאַטיאָן סטעפּס

1. מאַכט אַוועק: Ensure the power to the light fixture is turned off at the switch or circuit breaker.
2. סקרין אין: Screw the LoraTap Smart WiFi Bulb Socket into your existing E26 light fixture.
3. אַרייַנלייגן באַלב: Screw a compatible LED, CFL, Fluorescent, or Corn bulb into the smart socket.
4. מאַכט אויף: Restore power to the light fixture. The bulb should turn on.

בילד: Easy Installation. This image shows a person screwing a light bulb into the smart socket, and then the smart socket with bulb being installed into a lamp ייַנאָרדענונג.

4.3 אַפּ פּערינג

1. אראפקאפיע אַפּ: Download the 'Smart Life' or 'Tuya' app from your smartphone's app store (available on iPhone App Store and Android App Store).
2. רעגיסטרירן/אריינלאָגירן: עפֿנט די אַפּ און רעגיסטרירט זיך פֿאַר אַ נײַעם אַקאַונט אָדער לאָגט זיך אײַן אויב איר האָט שוין אײנס.
3. אַרייַן די פּערינג מאָדע: Press and hold the button on the smart socket until the light indicator starts flashing rapidly. This indicates it is in pairing mode.
4. לייג דיווייס: In the Smart Life app, tap the '+' symbol in the top right corner to add a new device. Select 'Lighting' > 'Light Source (Wi-Fi)'.
5. באַשטעטיקן בלינקען: Confirm that the indicator light is flashing rapidly in the app.
6. פאַרבינדן צו Wi-Fi: Enter your 2.4GHz Wi-Fi network name and password. Ensure your phone is also connected to the 2.4GHz network during this step.
7. פּאָרינג: The app will begin searching for and connecting to the device. Once connected, the device will be added successfully.
8. רענאַמע דיווייס: You can rename the device within the app (e.g., 'Kitchen Light') for easier control.

בילד: Easy Pairing. This image shows a step-by-step guide for pairing the smart socket with the Smart Life/Tuya app, including Wi-Fi compatibility confirmation (2.4GHz only), adding the device, entering Wi-Fi credentials, and successful device addition.

5. אַפּערייטינג ינסטרוקטיאָנס

5.1 אַפּ קאָנטראָל

Once paired, you can control your smart bulb socket from anywhere using the Smart Life app:

• קער אויף / אַוועק: Tap the switch icon in the app to turn the light on or off.
• רעאַל-צייט באַמערקונגען: The app provides real-time status of your light (on/off).
• גרופע קאָנטראָל: Group multiple smart sockets together to control them simultaneously.

בילד: App Control. This image shows a person using a smartphone with the Smart Life app interface, demonstrating how to turn a smart lamp holder on or off remotely.

בילד: Real-Time Feedback and Relay Status. This image displays the Smart Life app showing real-time on/off status of the light and options to set the relay status (ON, OFF, or Remember last status) after a power outage.

5.2 קול קאָנטראָל

Integrate your smart socket with Amazon Alexa or Google Home for convenient voice commands:

• פֿאַרבינדן אַקאַונטס: In the Alexa or Google Home app, link your Smart Life account.
• אַנטדעקן דעוויסעס: Ask Alexa or Google to discover new devices.
• קול קאַמאַנדז: Use commands like "Alexa, turn on Kitchen Light" or "Hey Google, turn off Bedroom Lamp."

בילד: Voice Control. This image shows a woman in a kitchen interacting with smart speakers (Google Home, Amazon Echo) to control a light, with a speech bubble indicating "Alexa, turn off kitchen light."

5.3 טיימער און סקעדזשול פונקציעס

Automate your lighting with various timer and scheduling options:

• פּלאַן: Set specific times for the light to turn on or off daily or on selected days.
• קאָונטדאָוון: Set a countdown timer for the light to turn off after a specified duration.
• Inching Timer: Set the light to turn off automatically after a short, adjustable period (e.g., 30 minutes) once turned on.
• Circulate Timer: Create recurring on/off cycles for specific periods, useful for simulating occupancy.

בילד: Timer and Schedule. This image displays the Smart Life app interface showing options to set daily schedules for turning lights on (e.g., 18:30) and off (e.g., 06:30).

בילד: Inching Timer and Circulate Timer. This image shows the app interface for setting an Inching Timer (e.g., 30 minutes) and a Circulate Timer with specific on/off schedules for different days.

5.4 מיטל ייַנטיילונג

Share control of your smart socket with family members:

• In the Smart Life app, navigate to the device settings.
• Select 'Share Device' and enter the accounts of family members you wish to grant access to.

בילד: Device Sharing. This image illustrates how to share control of the smart device with multiple family members through the app.

6. וישאַלט

To ensure optimal performance and longevity of your LoraTap Smart WiFi Bulb Socket, follow these simple maintenance guidelines:

• רייניקונג: Gently wipe the exterior of the smart socket with a dry, soft cloth. Do not use liquid cleaners or abrasive materials.
• קשר טשעק: Periodically ensure the smart socket is securely screwed into the light fixture and the bulb is firmly seated in the socket.
• Firmware דערהייַנטיקונגען: Check the Smart Life app regularly for any available firmware updates for your device. Updates can improve performance and add new features.
• ויסמיידן אָווערלאָאַדינג: דו זאלסט נישט יקסיד די מאַקסימום וואַסערtagE פון 30W.

7. טראָובלעשאָאָטינג

If you encounter issues with your LoraTap Smart WiFi Bulb Socket, refer to the following common solutions:

8. וואָראַנטי און שטיצן

LoraTap products are designed for reliability and performance. For warranty information, technical support, or any questions regarding your Smart WiFi Bulb Socket, please visit the official LoraTap website or contact their customer service directly. You can often find support contact details within the Smart Life or Tuya app under the 'Me' or 'Profile' section, or by searching for 'LoraTap support' online.
