VEMER Logik Micro DW Digital Timer Switch VP888200 User Manual

3.1. Physical Dimensions and Wiring Diagram

The following image illustrates the front and side dimensions of the Logik Micro DW, along with its electrical wiring diagram.

בילד באַשרייַבונג: This image displays three views of the VEMER Logik Micro DW VP888200. On the left, the "Vista frontale" (Front view) shows the device's height as 88mm and width as 18mm. In the center, the "Vista laterale" (Side view) indicates a depth of 60mm and a DIN rail clip height of 45mm. On the right, the "Schema" (Wiring Diagram) illustrates the electrical connections: L (Line) and N (Neutral) inputs, and the relay contacts labeled 1, 2, 3, 4, 5, 6. The diagram shows the internal relay switching between contacts for load control.

• פראָנט View: Height 88mm, Width 18mm.
• זייַט View: Depth 60mm, DIN rail clip height 45mm.
• וויירינג דיאַגראַמע:
  • L (Line) and N (Neutral): מאַכט צושטעלן אַרייַנשרייַב.
  • רעלע קאָנטאַקטן: The device features a single changeover relay (1 NO/NC contact). Connect the load according to the desired switching configuration.

4.1. ינסטאַלירונג

1. מאַכט דיסקאַנעקשאַן: Ensure the main power supply to the electrical panel is disconnected before beginning installation.
2. מאָונטינג: Mount the Logik Micro DW onto a standard 35mm DIN rail. The device occupies 1 DIN module.
3. וויירינג: Refer to the wiring diagram in Section 3.1.
   • Connect the Line (L) and Neutral (N) power supply wires to the designated terminals.
   • Connect the electrical load to the relay output terminals. The device has one changeover contact.
4. זיכער קאַנעקשאַנז: Ensure all wire connections are secure and properly tightened.
5. מאַכט רעסטאָראַטיאָן: Once installation is complete and verified, restore power to the electrical panel.

4.2. Initial Power-Up and Time Setting

ביים ערשטן אויפשטעל אדער נאך א פארלענגערטן אויסשטעלtage, the display may show default settings or require time synchronization.

1. ווייַז אַקטאַוויישאַן: The LCD display will activate. If it's blank, ensure power is supplied correctly.
2. שטעלן די איצטיקע צייט און טאָג: Use the device's buttons (refer to the specific button layout on the device, not detailed in provided data) to set the current time and day of the week. This is crucial for accurate program execution.

5.1. פּראָגראַמירן מאָדעס

• טעגלעכע פּראָגראַממינג: Programs repeat every day at the same set time.
• וויקלי פּראָגראַממינג: Programs can be set for specific days of the week or groups of days.

5.2. Setting ON/OFF Programs

The device supports up to 20 ON/OFF programs. Each program consists of an ON time and an OFF time.

1. אַרייַן די פּראָגראַממינג מאָדע: Press the designated button (e.g., "PROG" or "SET") to enter the programming menu.
2. Select Program Number: Choose an available program slot (e.g., P1, P2, ..., P20).
3. שטעלן אן צייט: Input the desired time for the load to switch ON.
4. אויסשטעלן צייט: Input the desired time for the load to switch OFF.
5. אויסקלייבן טעג: Choose the days of the week for the program to be active (e.g., Mon-Fri, Sat-Sun, or specific days).
6. Save Program: Confirm and save the program. Repeat for additional programs.

The programming resolution is 1 minute, allowing for precise control.

5.3. Impulse Programming

The device also supports impulse programming, where the relay briefly activates for a set duration.

1. אַרייַן די פּראָגראַממינג מאָדע: אַקסעס די פּראָגראַממינג מעניו.
2. Select Impulse Program: Choose an impulse program slot.
3. Set Impulse Time: Define the time when the impulse should occur.
4. Set Impulse Duration: Specify how long the relay should remain active (e.g., 1-59 seconds).
5. אויסקלייבן טעג: Choose the days for the impulse program.
6. Save Program: באַשטעטיקן און ראַטעווען.

5.4. מאַנואַל אָווועררייד

The device typically includes a manual override function to temporarily switch the load ON or OFF independently of the programmed schedule. Consult the device's physical buttons or display menu for this function.

6.1. רייניקונג

To clean the device, gently wipe the exterior with a soft, dry cloth. Do not use abrasive cleaners, solvents, or spray liquids directly onto the device.

6.2. Battery Reserve

The Logik Micro DW features a rechargeable lithium battery that provides a power reserve of approximately 3 years. This reserve maintains the time and programmed settings during power outages. The relay will only switch in the presence of mains power.

• The battery is internal and not user-replaceable.
• Regular operation with mains power will keep the battery charged.
