פּראָדוקט איבערview
The Westbrass D400-1-62 P-Trap is designed for use in bathroom or kitchen sink installations. This 1-1/2 inch OD, 17 gauge brass tubular P-trap includes a matching high box flange for a finished appearance. It features brass lock nuts on the neck and J-bend connections for secure installation.
- Complete P-Trap Set: Standard 1-1/2 inch OD, 17 Gauge Brass Tubular P-Trap with matching High Box Flange.
- Premium Brass Durability: Heavy-duty 17 Gauge brass construction for corrosion resistance and long-lasting performance.
- גענויע מעסטונגען: Approximately 11-1/2 inches from center of neck to end of tailpiece.
- וניווערסאַל קאַמפּאַטאַבילאַטי: Suitable for standard residential and commercial sink installations with 1-1/2 inch drain configurations.
- גרינג ינסטאַלירונג: Kit includes slip joint nuts and all necessary hardware.
This image shows the complete Westbrass D400-1-62 P-Trap assembly in a matte black finish. It highlights the main components: the P-trap bend, the horizontal arm, and the high box flange.
סעטאַפּ און ינסטאַלירונג
Follow these steps for proper installation of your Westbrass D400-1-62 P-Trap. Ensure all components are present before beginning.
- Prepare the Drain: Ensure the sink tailpiece and wall drain pipe are clean and free of debris.
- Attach the High Box Flange: Slide the high box flange onto the horizontal arm of the P-trap. This flange will sit flush against the wall for a clean aesthetic.
- Connect to Tailpiece: Connect the vertical inlet of the P-trap to the sink's tailpiece using a slip joint nut and washer. Hand-tighten first, then use a wrench for a snug fit, being careful not to overtighten.
- Connect to Wall Drain: Align the horizontal arm of the P-trap with the wall drain pipe. Use a slip joint nut and washer to secure this connection. Adjust the P-trap's position to ensure proper alignment and a slight downward slope towards the wall drain for optimal drainage.
- פֿאַרשטאַרקן אַלע פֿאַרבינדונגען: Once aligned, securely tighten all slip joint nuts. Avoid excessive force to prevent damage to the brass components or washers.
- טעסט פֿאַר ליקס: Run water through the sink for several minutes and carefully inspect all connections for any signs of leakage. If leaks occur, tighten the affected connections slightly.
This image displays the separate components of the P-trap assembly, including the main P-trap unit and the high box flange, ready for installation.
This specification sheet provides detailed measurements and a diagram of the P-trap, including the 1-1/2 inch OD and the overall dimensions, which are crucial for planning the installation space. It also shows the included washers.
This image illustrates the P-trap installed beneath a sink, demonstrating how it connects to the tailpiece and extends to the wall drain, providing a visual reference for the completed setup.
אַפּערייטינג פּרינסאַפּאַלז
The Westbrass D400-1-62 P-Trap functions as a critical component of your plumbing system by creating a water seal. This seal prevents sewer gases and odors from entering your living space through the drain. When water flows through the sink, a small amount remains in the P-trap's U-bend, forming this essential barrier.
This diagram visually explains how the classic P-trap design retains water to create a barrier, effectively preventing sewer gases from escaping into the room, thus maintaining a fresh and hygienic environment.
וישאַלט
Regular maintenance ensures the longevity and proper function of your P-trap.
- רעגולער רייניקונג: Periodically flush the drain with hot water to help prevent grease and soap buildup.
- ויסמיידן האַרב קעמיקאַלז: Do not use strong chemical drain cleaners, as they can corrode brass and damage seals over time. Use enzymatic cleaners or a mixture of baking soda and vinegar for minor clogs.
- טשעק פֿאַר ליקס: Occasionally inspect the P-trap connections for any signs of drips or moisture, especially after heavy use. Tighten connections if necessary.
- ויסמעקן בלאַקידזשיז: If a clog occurs, the P-trap can be disassembled to remove debris. Place a bucket underneath before loosening the slip nuts to catch any water.
This image highlights the P-trap's design, emphasizing its simple structure which allows for straightforward disassembly and cleaning, contributing to long-term, trouble-free operation.
טראָובלעשאָאָטינג
| פּראָבלעם | מעגלעך סיבה | לייזונג |
|---|---|---|
| לעקס ביי קאַנעקשאַנז | Loose slip nuts, damaged washers, improper alignment. | Ensure slip nuts are tightened securely (hand-tight plus a quarter turn with a wrench). Check washers for proper seating and damage; replace if necessary. Verify correct alignment of pipes. |
| Slow drainage or clog | Accumulation of hair, soap scum, or debris in the P-trap. | Disassemble the P-trap (place a bucket underneath) and manually remove any blockages. Clean the interior of the trap. Reassemble and test. |
| Sewer odors | P-trap water seal has evaporated or been siphoned. | Run water for a minute to refill the P-trap. If the problem persists, check for proper venting in your plumbing system. |
ספּעסאַפאַקיישאַנז
| שטריך | דעטאַל |
|---|---|
| מאָדעל נומער | דקסנומקס-קסנומקס-קסנומקס |
| סאָרט | וועסטברעס |
| מאַטעריאַל | מעש |
| גרייס | 1-1/2 inch OD, 17 Gauge |
| קאָליר | מאַט שווארצע |
| פּראָדוקט דימענשאַנז | בעערעך 12 X 1.5 X 6 אינטשעס (L X W X H) |
| פּונקט וואָג | 1.2 פונט |
| אַרייַנגערעכנט קאַמפּאָונאַנץ | (1) - P-Trap with Flange |
This image provides a detailed dimensional drawing of the P-trap, including measurements such as the 1-1/2 inch diameter, 8-3/4 inch length from the wall, and other critical dimensions for installation planning.
וואָראַנטי אינפֿאָרמאַציע
The Westbrass D400-1-62 P-Trap is covered by a 1 יאָר לימיטעד וואָראַנטי. This warranty covers defects in materials and workmanship under normal use and service. For specific terms and conditions, please refer to the official Westbrass warranty documentation or contact Westbrass customer support.
קונה שטיצן
For further assistance, technical support, or warranty claims regarding your Westbrass D400-1-62 P-Trap, please contact Westbrass customer service.
- סאָרט: וועסטברעס
- Webפּלאַץ: www.westbrass.com (Please note: This is a general link, specific support contact information may be found on the official product page or packaging.)
