JOMISE D530 4K Dual Dash Cam User Manual

1. הקדמה

Thank you for choosing the JOMISE D530 4K Dual Dash Cam. This manual provides essential information for setting up, operating, and maintaining your device. Please read it thoroughly before use to ensure proper functionality and safety.

2. פּראָדוקט איבערview

שליסל פֿעיִקייטן

• פראָנט אַפּאַראַט: 4K (3840x2160P) video recording.
• דערציען אַפּאַראַט: 1080P video recording.
• געבויט-אין GPS: Records driving route, speed, and other location data.
• געבויט-אין WiFi: Connects to a mobile app for live viewing, settings adjustment, and video download.
• 3-אינטש IPS פאַרשטעלן: Clear display for real-time monitoring and playback.
• 170° ברייט ווינקל לינז: Comprehensive coverage of the road.
• JOMISE Starvis Sensor: Enhanced low-light performance.
• סופּער קאַפּאַסיטער: Provides reliable power in extreme temperatures and extends lifespan.
• 32GB SD קאָרט אַרייַנגערעכנט: גרייט פֿאַר באַלדיקן באַנוץ.

פּעקל אינהאַלט

The JOMISE D530 package includes the following items:

• JOMISE D530 Front Dash Cam
• Rear Camera with connection cable
• Car Charger (Cigarette Lighter Adapter)
• GPS Module (integrated into mount)
• 32 גיגאבייט מיקראָ סד קאָרט
• באַניצער מאַנואַל
• Mounting accessories (adhesive pads, cable clips)

Image: Contents of the JOMISE D530 Dash Cam package.

3. סעטאַפּ

3.1 ינסטאַלירונג

1. רייניקן ווינטשילד: זייט זיכער אז די געגנט אויף אייער ווינטשילד וואו די דעש קאַם וועט זיין מאָנטירט איז ריין און טרוקן.
2. צוטשעפּען פראָנט קאַמעראַ: Secure the front dash cam to the windshield using the provided adhesive mount. Position it to ensure a clear view פון דער וועג אָן צו שטערן אייער זעאונג ביים דרייווינג.
3. אינסטאַלירן הינטערשטע קאַמעראַ: Mount the rear camera on the rear windshield. Connect the rear camera cable to the main unit. For reverse assist functionality, connect the red wire from the rear camera cable to your vehicle's reverse light power supply.
4. פאַרבינדן מאַכט: Plug the car charger into your vehicle's cigarette lighter socket and connect the other end to the main dash cam unit. Route the cable neatly along the windshield and dashboard using the provided cable clips.
5. אַרייַנלייגן SD קאָרט: Insert the 32GB Micro SD card (or a larger compatible card, up to 256GB) into the designated slot on the dash cam.

Image: Front dash cam mounted on the windshield.

3.2 ערשט קאַנפיגיעריישאַן

Upon first power-on, the dash cam may prompt you to set the date and time. Follow the on-screen instructions. It is recommended to format the SD card through the dash cam's menu before first use.

Video: This video demonstrates the installation process and key features of the JOMISE D530 Dash Cam.

4. אַפּערייטינג ינסטרוקטיאָנס

4.1 יקערדיק אָפּעראַציע

• מאַכט אויף / אַוועק: The dash cam will automatically power on and start recording when your vehicle starts, and power off when the engine is turned off.
• שלייף רעקאָרדינג: The device records video in continuous loops. When the SD card is full, the oldest unlocked files זענען אָוווערריטאַן.
• G-Sensor & Emergency Recording: In case of a sudden impact or collision, the built-in G-sensor will automatically lock the current video file צו פארמיידן אז עס זאל איבערשרייבן.
• פּאַרקינג מאָניטאָר: With a hardwire kit (sold separately), the dash cam can monitor your vehicle while parked, recording incidents or using time-lapse recording to save storage space.

Image: Illustration of the G-Sensor and Emergency Recording feature.

Image: Time-lapse recording for extended parking surveillance.

4.2 דזשי-פי-עס פונקציאָנאַליטעט

The built-in GPS module records your vehicle's location, speed, and driving route. This data can be viewed using the dedicated PC player software (DVPlayer), which can be downloaded from the official JOMISE website. The software allows you to synchronize video playback with your route on a map.

Image: Dash cam screen displaying GPS information and speed.

4.3 WiFi און אַפּ פֿאַרבינדונג

Download the "OK CAM Plus" app from your smartphone's app store. Enable Wi-Fi on your dash cam via the settings menu. Connect your smartphone to the dash cam's Wi-Fi network (SSID and password displayed on the dash cam screen). Through the app, you can:

• View לעבן פאָאָtagע פון ​​ביידע קאַמעראַס.
• אַדזשאַסטירן דאַש קאַם סעטטינגס.
• דאַונלאָוד רעקאָרדירטע ווידעאָס און פאָטאָס גלייך צו דיין טעלעפאָן.
• Share content to social media.

Image: Smartphone displaying live view from the dash cam via the mobile app.

4.4 Enhanced Night Vision

The JOMISE D530 utilizes a SONY Starvis sensor and Wide Dynamic Range (WDR) technology to provide clear video quality in low-light conditions. This helps to balance exposure and suppress glare from headlights, improving visibility during night driving.

Image: Visual representation of WDR technology improving image clarity in varying light conditions.

5. וישאַלט

5.1 סד קאָרט פאַרוואַלטונג

• פֿאָרמאַטירונג: Regularly format the SD card (at least once a month) to ensure optimal performance and prevent data corruption. This can be done through the dash cam's settings menu.
• פאַרבייַט: Replace the SD card every 6-12 months, depending on usage, as continuous overwriting can degrade its performance.

5.2 רייניקונג

• לענס: Use a soft, lint-free cloth to gently clean the camera lenses. Avoid abrasive materials or chemical cleaners.
• פאַרשטעלן: ווישן די פאַרשטעלן מיט אַ ווייך, טרוקן שטאָף.

6. טראָובלעשאָאָטינג

• דאַש קאַם גייט נישט אָן: Check the car charger connection and ensure the vehicle's cigarette lighter socket is functioning.
• רעקאָרדינג ישוז: Ensure the SD card is inserted correctly and has sufficient free space. Format the SD card. If issues persist, try a new SD card.
• נעבעך ווידעא קוואַליטעט: Clean the camera lenses. Ensure the protective film is removed from the lenses. Adjust exposure settings if necessary.
• GPS ארבעט נישט: Ensure the GPS module is properly connected and the vehicle is in an open area with clear sky view.
• Wi-Fi קאַנעקשאַן פּראָבלעמס: Restart both the dash cam and your smartphone. Ensure you are within range of the dash cam's Wi-Fi signal.

7. ספּעסאַפאַקיישאַנז

8. וואָראַנטי און שטיצן

JOMISE products come with a standard manufacturer's warranty. For detailed warranty information, technical support, or any inquiries regarding your D530 Dash Cam, please refer to the official JOMISE website or contact JOMISE customer service directly. Contact information can typically be found in the packaging or on the product's support page online.
