VOUNOT 3x3M Folding Garden Gazebo Instruction Manual

1. זיכערקייַט אינפֿאָרמאַציע

ביטע ליינט אלע זיכערהייט אינסטרוקציעס איידער איר שטעלט עס צוזאם און ניצט עס. אויב איר פאלגט נישט די אינסטרוקציעס קען דאס פירן צו שאָדן אדער שאָדן צום פּראָדוקט.

• This gazebo is designed for temporary use and is not intended to be left unattended or used during adverse weather conditions such as strong winds, heavy rain, or snow.
• Ensure the gazebo is securely anchored to the ground using the provided pegs, ropes, and sandbags to prevent it from being lifted by wind.
• Be careful to prevent rainwater accumulation on the roof, as excessive weight can damage the frame. Regularly clear any standing water.
• Keep children and pets away from the assembly area to avoid accidents.
• Do not use open flames or heating appliances inside or near the gazebo.

2. פּעקל אינהאַלט

באַשטעטיקן אַז אַלע קאָמפּאָנענטן זענען פאַראַן איידער איר הייבט אָן די פֿאַרזאַמלונג.

• 1x Folding Gazebo Frame
• 1x Gazebo Roof Canopy (Green)
• 4x Sandbags (for weight)
• 8x פּעגס
• 4x Tension Ropes
• 1x קאַררי באַג
• 1x ינסטרוקטיאָן מאַנואַל

Figure 2.1: Included accessories for the VOUNOT Gazebo. This image displays the folding steel frame, the green waterproof roof canopy, a green carry bag, four white tension ropes, eight silver pegs, and four black sandbags.

3. סעטאַפּ אינסטרוקציעס

The gazebo features a pop-up design for quick assembly and disassembly. For optimal stability and to prevent damage, two people are recommended for setup.

3.1 Unfolding the Frame

1. Place the folded frame in the desired location.
2. With one person on each side, gently pull the outer legs of the frame outwards. Apply even pressure to ensure the frame expands uniformly.
3. Avoid applying strong pressure to one side or allowing the frame to expand unevenly, as this can damage the connectors.

Figure 3.1: Illustration demonstrating the correct method for unfolding the gazebo frame with two people, applying even pressure, versus the incorrect method by one person, which can cause damage.

3.2 Attaching the Roof Canopy

1. Once the frame is partially expanded, place the roof canopy over the top.
2. צופּאַסן די ווינקלען פֿון דער קאַנאָפּי מיט די ווינקלען פֿון דער ראַם.
3. Secure the canopy to the frame using the integrated straps or ties.

3.3 Extending the Legs and Securing

1. Fully extend the legs of the gazebo to the desired height, ensuring all locking mechanisms are engaged.
2. Fill the four sandbags with sand and attach them to the gazebo legs for additional weight and stability.
3. Use the provided pegs to anchor the gazebo legs to the ground, especially on soft surfaces like grass.
4. Attach the tension ropes to the corners of the canopy and stake them into the ground at an angle to provide extra wind resistance.

פיגורע 3.2: דעטאַילעד views showing how the roof is secured to the frame, the leg height adjustment mechanism, and a sandbag attached to a gazebo leg for stability.

4. אָפּעראַציע

The VOUNOT Folding Garden Gazebo provides a shaded area for various outdoor activities.

• זון שוץ: The polyester roof with PA coating offers effective protection from the sun.
• ווערסאַטאַל נוצן: Ideal for family gatherings, picnics, parties, outdoor events, camping, and commercial use.

פיגורע 4.1: עקסamples of the gazebo's versatile applications, including picnics, garden relaxation, market stalls, and festivals.

5. וישאַלט

Proper maintenance will extend the lifespan of your gazebo.

• רייניקונג: Clean the canopy and frame with mild soap and water. Avoid harsh chemicals that could damage the fabric or paint.
• דרייינג: זיכער מאַכן אַז די קאַנאַפּי איז גאָר טרוקן איידער איר פאָלדט און לייגט עס אַוועק צו פאַרמייַדן שימל און פוילעכץ.
• סטאָרידזש: Store the gazebo in its carry bag in a dry, cool place when not in use.
• דורכקוק: Regularly inspect the frame for any signs of damage or wear. Check all connections and locking mechanisms.
• Rainwater: Do not allow rainwater to accumulate on the roof. This can cause the frame to bend or break.

6. טראָובלעשאָאָטינג

Common issues and solutions for your gazebo.

• גאַזעבאָ איז נישט סטאַביל: Ensure all legs are fully extended and locked. Verify that sandbags are filled and attached, and pegs and tension ropes are properly secured.
• Frame difficult to unfold/fold: Ensure two people are assisting with the process, applying even pressure. Do not force the frame. Check for any obstructions or bent parts.
• וואַסער זאַמלט זיך אויף דאַך: This indicates insufficient tension or improper setup. Ensure the canopy is taut and properly secured to the frame. Regularly clear any accumulated water.
• Damage to frame/connectors: This often occurs from uneven pressure during setup or use in high winds without proper anchoring. Always assemble with care and secure the gazebo adequately for weather conditions.

7. ספּעסאַפאַקיישאַנז

Figure 7.1: Product specifications including dimensions (300cm x 300cm x 220cm height, 30cm roof peak) and folded size (120cm x 20cm x 18cm).

8. וואָראַנטי און שטיצן

For warranty information or customer support, please refer to the purchase documentation or contact VOUNOT customer service through the retailer where the product was purchased.
